Double Acting Hydraulic Cylinder / Silinder Hidrolik 10 Ton 300mm Stroke - HHYG-10300S - BARTON
Description
Request
Informasi Pemesanan
Untuk order ini silahkan isi form dibawah ini
Team marketing kami akan segera menghubungi anda dan memberikan anda solusi dan harga terbaik untuk keperluan anda.
Name
Email
Telephone
Message
Keluar
Download Catalogue
Tweet
Specifications
Model
HHYG-10300S
Pump System
Double Acting
Cylinder Capacity @700 Bar
10Ton 111KN (Push) 70KN (Pull)
Stroke
300 mm
Effective Area (Push)
19.6 cm²
Effective Area (Pull)
10 cm²
Oil Capacity (Push)
589 ml
Oil Capacity (Pull)
300 ml
Closed Height
430 mm
Extended Height
730 mm
Outside Diameter
70 mm
Inside Diameter
50 mm
Piston Rod Diameter
35 mm
Handle
No
Recommended Pump
Double Acting Min. 3L
Packing Weight
11 kg
